YAK 312 - Air-hydraulic jack

Practical and effective air-hydraulic jacks. The pistons move back automatically; the two descent valves guarantee perfect holding in all situations and controlled speed under load.

Specific for buses, coaches and public transport vehicles.

Capacity:	60/30/15 t 66.1/33.1/16.5 ton
Net weight:	44 kg 97 lb
Working air pressure:	8-10 bar 116-145 psi
Air consumption:	600 Nl/min
Stroke:	132 mm 5.2 in
Min. height:	120 mm 4.7 in
Number of pistons:	3
Pistons stroke:	43 - 38 - 51 mm 1.7 - 1.5 - 2 in
